KRX18-500 Straight Plug_2D drawing
Gerneral Information
Product Type: | DC Combiner Box | Shell Material: | SUS/Carbon Steel/Aluminum Alloy/Plastic |
Voltage Range: | 48V-1500V DC | Dimensions: | Customer Requirements |
| Input/output: | Gland/Connector | Busbar Material: | Copper |
Bolt Material: | SUS Bolt Fixation | Output current: | 100A-400A |
| Fuse: | Various Types Manufacturers | SPD/Breaker: | Various Types and Manufacturers |
| Installation: | Wall Mounted | Temperature Range: | -35°C ~ 85°C |
MOQ: | 1pcs Supply Custom Service | Draft Proposal Timeline: | 3-5 days |
Production Timeline: | 25-35 days | Packaging Details: | Carton or Wooden Case |
Features & Benefits
In your compact DC Combiner Box, we can integrate several vital functions, including:
2D drawing and 3D models constructions
From prototype to series production experience
Design, develop, and production One-Stop service
Reliability and durability with a temperature-optimized design
Flexible Integrated with Fuses/DC Isolation/DC Surge Protection
In-house laboratory/tests (Appearance, functional and temperature tests)
Wide DC voltage input range with maximum open-circuit voltage up to1500V
Compatible and individual with configuration in accordance with customer requirements
Your DC Combiner Box Internal Components Select Expert --- Variety, Reliable, Qualify, Customizable, Simple
We have established in-depth and long-term cooperative relations with well-known foreign internal components manufacturers, Example of LS, TE, Saltbol, Siemens, Mersen, Bussman, Honeywell, LEM, Schaffner, etc. For economic choice, China Top brands are also a good option, like SCII, Sinofuse, KRX connectors, etc. With professional component experiences, we can supply you with the fast optimized options with short component delivery.
Housing: We can supply many different options to meet your different requirements and ambient conditions. Material options for Stainless steel, Carbon steel, aluminum alloy, and Plastic. Structure selection for standard, customized, or mold processing. Coating options for powder painting and spray painting.
Connection: Regarding the busbar connection, there are also insulation and without insulation options, the busbar coating can also be selected if you need it.
Function controls: In addition to our standard functions, the customer-specific control units also can be customized for customer requirements.
Various components configuration: Many cooperation manufacturers' selection can realize lightning protection, short circuit protection, and grounding protection. It can also detect inside temperature, detect lightning protection status, detect circuit breaker status, summarize output voltage, and so on.
Excellent Key Technologies
Our advantage
Unique Customization
Various configurations through the use of proven components.
Individually adaptable to applications & customer requirements.
Optimized Design
Compact & Low weight design in your customized Busbar Box.
Adapt to the harsh environment, easy installation & maintenance.
Flexible Selction & Configuration
Many cooperation manufacturers' selection of Fuses/DC Isolation/DC Surge Protection.
Compatible and individual with configuration in accordance with customer requirements.
Safty Consideration
Realize lightning protection, short circuit protection and grounding protection.
Provide users with a safe, brief, beautiful and applicable photovoltaic system products.
Product Applications
Examples of our Busbar box have been widely used:
Energy storage system
Electric Vehicle Charging Stations
Marine and Offshore Engineering
Aerospace and microgrid system
Photovoltaic Power Generation SystemsThis is not a list of definitions of applications for this product. It represents some of the more common uses.
Your Normal FAQS
Q1: How long is the timeline for developing a Busbar Box?
The development timeline depends on the different requirements, project scope, and customer specifications, and we will share with you the first draft 3D drawing within 3-5 days.
Q2: What components are included in the DC Combiner Box?
The components vary based on the application and customer requirements. Key components and functions include:
Internal DC Isolation
DC Surge Protection
Larger Amperage Fuses
Cables and busbar connections
Connector or Cable Gland options
Q3: Can the components of the DC Combiner Box be specified?
Of Course, Yes! We can communicate with relevant component manufacturers based on your specified brand or model, to production selection and DC Combiner Box design accordingly.
If you don't have specific requirements for the components, we can help you to select suitable and reliable components based on your real requirements.
Q4: What can you obtain once the final DC Combiner Box proposal is frozen?
We can supply 2D/3D drawing, final BOM list, PDU schematic, and other documents you may need.
