KRX18-500 Straight Plug_2D drawing
Gerneral Information
Product Type: | Busbar Box | Shell Material: | SUS/Carbon Steel/Aluminum Alloy/Plastic |
Voltage Range: | Upto 1500V DC | Dimensions: | Customer Requirements |
| Input/output: | Gland/Connector | Busbar Material: | Copper |
Bolt Material: | SUS Bolt Fixation | Output current: | 100A-400A |
MOQ: | 1pcs Supply Custom Service | Draft Proposal Timeline: | 3-5 days |
Production Timeline: | 25-35 days | Packaging Details: | Carton or Wooden Case |
Features & Benefits
2D drawing and 3D models constructions
From prototype to series production experience
Design, develop, and production One-Stop service
One-stop solution for your BusBar box requirements
BusBar enclosures offer for different classifications, types, and sizes
KRX focused to give you excellent manufacturing services
In-house laboratory/tests (Appearance, functional and temperature tests)
Wide DC voltage input range with maximum open-circuit voltage up to1500V
Your Busbar Box Select Expert --- Variety, Reliable, Qualify, Customizable, Simple
We have established in-depth and long-term cooperative relations with well-known foreign internal components manufacturers, Example of LS, TE, Saltbol, Siemens, Mersen, Bussman, Honeywell, LEM, Schaffner, etc. For economic choice, China Top brands are also a good option, like SCII, Sinofuse, KRX connectors, etc. With professional component experiences, we can supply you with the fast optimized options with short component delivery.
Housing: We can supply many different options to meet your different requirements and ambient conditions. Material options for Stainless steel, Carbon steel, aluminum alloy, and Plastic. Structure selection for standard, customized, or mold processing. Coating options for powder painting and spray painting.
Connection: Regarding the busbar connection, there are also insulation and without insulation options, the busbar coating can also be selected if you need it.
Function controls: In addition to our standard functions, the customer-specific control units also can be customized for customer requirements. The plated copper Strips are fitted in steps for easy cable connections and are known for superior conductivity which makes power distribution easier and long operational life.
Excellent Key Technologies
Our advantage
Unique Customization
Various configurations through the use of proven components.
Individually adaptable to applications & customer requirements.
Optimized Design
Compact & Low weight design in your customized Busbar Box.
Adapt to the harsh environment, easy installation & maintenance.
Flexible Selction & Configuration
There are also insulation and without insulation options, the busbar coating can also be selected.
Compatible and individual with configuration in accordance with customer requirements.
Safty Consideration
Provide users with a safe, brief, beautiful products.
Enclosures are made from thick Steel , protected with powder coated to prevent from corrosion.
Product Applications
Examples of our Busbar box have been widely used:
Energy storage system
Military electric vehicles
Marine and Aerospace system
Battery Electric Vehicles (BEV)
Electric and hybrid vehicles (HEV)
Off-Highway Electric Vehicles
Electric Forklifts Electric Tractors
Electric construction machinery and commercial vehiclesThis is not a list of definitions of applications for this product. It represents some of the more common uses.
Your Normal FAQS
Q1: How long is the timeline for developing a Busbar Box?
The development timeline depends on the different requirements, project scope, and customer specifications, and we will share with you the first draft 3D drawing within 3-5 days.
Q2: What components are included in the Busbar Box?
Key components and functions include:
Insulation material
Internal copper busbar
Busbar Box Shell options
Connector or Cable Gland options
Q3: What can you obtain once the final Busbar Box proposal is frozen?
We can supply 2D/3D drawing, final BOM list, schematic, and other documents you may need.
