KRX18-500 Straight Plug_2D drawing
Gerneral Information
| Product Type | HV Wire Harness | Connector Options | KRX/TE/Amphenol/Jonhon, etc. |
Color | Orange | Crimping Range | 2.5 mm²-300 mm² |
Rate Current | 20A-800A | Withstand Voltage | 2300V |
Mounting Type | Terminal Crimp | Ingress Protection | IP67 |
Shield | Support | HVIL | Support |
Material | XLPO (Halogen Free) | Temperature Range | -40°C ~ 125°C |
MOQ | No MOQ Limited | Custom Design | Support |
Production Timeline | 10-15 days | Packing Details | Carton or Wooden Case |
Features & Benefits
Provide wire harness processing services.
Standard connectors for quick and easy installation.
Crimping range: 2.5-300mm², the voltage upto 2300V.
100% breakover and high voltage test and air tight test.
Compliant with UL , REACH and RoHS specifications and certificate.
Full range of HV connectors for safe, reliable and efficient interconnection.
Full customized supports on all your high voltage interconnection requirements.
The shielded cable design shields up to 95% EMI coverage and complies with EMC requirements.
The cables are available in different sizes, lengths and configurations to meet the needs of your application.
The high voltage cable assemblies include unshielded cables , shielded cables, single and multi-core cables options.
The safe and reliable high voltage harness assemblies are combined with the most advanced technologies such as high voltage interlock loop (ensures safe interconnection between EV batteries and charge controllers), electromagnetic shielding (provides protection against electromagnetic interference) and mechanical shock response (protects against sudden impacts during road collisions or off-road driving conditions), to ensure safe interconnection of EVs.
Excellent Key Technologies
Our advantage
Safety Consideration
KRX's high-voltage wire harnesses are engineered for precision crimping and flame-retardant materials to prevent arcing or overheating. Every unit undergoes hi-pot testing (2500V+) and 100% continuity checks to ensure reliability.
Compliance & Certifications
KRX selects and uses high-voltage cables that have passed the UL, TUV, and REACH certificates, ensuring compliance with international safety and performance standards.
Precision Crimping Technology
Automated crimping processes with <2% tolerance for consistent contact resistance. 100% pull-test verification on all terminations. Silver-plated connectors to reduce oxidation
Quality Control & Testing
Our quality control system ensures every high-voltage wire harness meets the highest reliability standards through. In-line testing, 100% continuity checks, and environmental stress tests.
Customization & Compatibility
We specialize in collaborative wire harness development with OEM collaboration, modular designs, and rapid prototyping.
HV Cable Specification
Customer Cases Of Wire Harness Drawing
Product Applications
Our High-voltage connectors are used in a wide range of industries, including electric vehicles, electric boats, energy storage system, Evtol, railway transportation, etc.
DC-to-DC Converters
AC/DC Charging Station
Electric Vehicles
Motor controller
High-current battery pack
Hybrid electric vehicle
HV Power Distribution Units
PTC & Auxiliary
On-Board Charger (OBC)
Inverters
HV Wire Harness
This is not a list of definitions of applications for this product. It represents some of the more common uses.
